型号 Type |
XK-150 |
XK-250 |
XK-300 |
XK-360 |
X(S)K-400A |
X(S)K-450A |
X(S)K-560 |
|
辊筒工作直径 Working diameter of rolls(mm) |
θ150 |
θ250 |
θ300 |
θ360 |
θ400 |
θ450 |
θ560 |
|
辊筒工作长度 Working length of rolls (mm) |
280 |
620 |
750 |
900 |
1000 |
1200 |
1530 |
|
前辊筒线速度 Working linear speed of front rall(m/min) |
11.24 |
14.4 |
15.1 |
16.25 |
18.65 |
24.5 |
29.09 |
|
前后辊筒速比 Friction ratio of front and rear roll(m/min) |
1:1.4 |
1:1.17 |
1:1.27 |
1:1.25 |
1:1.27 |
1:1.27 |
1:1.2 |
|
最大辊距 Max gap(mm) |
8 |
8 |
8 |
10 |
10 |
15 |
20 |
|
一次加料量 Capacity per.batch(kg) |
1-2 |
10-15 |
15-20 |
20-25 |
18-35 |
25-50 |
50-65 |
|
驱动电机功率 Driving motor power(kw) |
7.5 |
18.5 |
22 |
30 |
37 |
55 |
90 |
|
外形尺寸
Overall dimensions(mm) |
长L |
1080 |
3400 |
1550 |
1850 |
2380 |
2282 |
|
|
宽W |
796 |
1500 |
1550 |
1850 |
1850 |
2380 |
2282 |
|
高H |
1415 |
1500 |
1695 |
1740 |
1870 |
1770 |
2000 |
|
质量 Weight (kg) |
1100 |
3500 |
5200 |
6500 |
7600 |
13000 |
22000 |
|
注
Notes |
轴承传动
Bearing |
尼龙瓦为干油润滑
Nylon bush grease LUB |
铜瓦为稀油润滑
Copper sieeve oil LUB |
尼龙瓦为干油润滑
Nylon bush grease LUB |
